Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work (1909)

Johnson, Alfred Sidney, 1860-, Radford, William A., 1865- · Chicago Radford Architectural Co · leaf 173

An illustration from Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work, 1909, leaf 173
^have the grain of the wood run in the samedirection as the grain in the tread. The returnnosing is then fastened into place by gluing 146 FRAMING the tongue and the groove, and driving thenosing to a tight fit. Another way to fasten the nosing is to cutnotches on the under side of the tread, and… … Fig. 80. Construction and Finish of Open Stairs. outside of the baluster should be flush with theface of the string; and where a bracket is used,this must be considered the face of the string.Various Stair Arrangements. There aremany ways of building stairs; what may be suit-able in one place, may…
