opened.The inside soffit of the window is paneled. Theframe is rebated for the sash, and the outsidecasing is moulded as shown. A vertical section taken through the transombar of the window is given at 188, and showsthe transom sash and bar with a rebated joint,and the sash with an undercut. The… … &rortir ■bi-uu Tig 103, Inward-Opening Casement Bay. A vertical section (189) is taken through thesill of the window, and shows a method of con-struction similar to those already illustrated.The stool is tongued into the sill, and the sill and 200 FRAiVIING sash are rebated. The sash has two…
