Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work (1909)

Johnson, Alfred Sidney, 1860-, Radford, William A., 1865- · Chicago Radford Architectural Co · leaf 78

An illustration from Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work, 1909, leaf 78
m, rainyweather. The same is true of second-story case-ments in gables or elsewhere where not pro-tected by the eaves. The best method of fitting screens and stormsash to casements is to hinge them at the top,fitting them with a small bolt or catch to holdthem in position at the bottom so that they… … CA5EJMQ.iTr WINDOW DEDML5 HEAD5 JAAAB5 ^ 5ILLS \y^ STOCKSA5M \% TliICK 3»V WID£ OVQ2 ALLBOTTO/A I2AIL5 445C12£E/N^ % STOCK HU/NG AT TOP IfiS^AALL L005L Pin BI^A5S BUTT5Fig. 28. Framing for Inward-Opening Casements. The accompanying details all show sufficientspace in the jamb-lining next to the…
