Radford's portfolio of details of building construction : a remarkable and unique collection of full-page plates, accurately drawn and reproduced to exact scale ... (1911)
Radford, William A., 1865-, Johnson, Bernard L, Rawson, Charles P · Chicago : The Radford Architectural Company · leaf 70
of the year. Note use of 3 by 6studs and 1 by 2 furring strips (F) which formthe double-plaster space. Fig. 96, section throughjamb. Fig. 97, section through window sill. Fig. 98, another form of wall construction; sectionthrough window jamb showing storm sash sub-stituted for blinds when cold…
Building · Architecture
Internet Archive · University of Toronto, Robarts Library · Public Domain Mark 1.0. Free to use for anything.
