Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work (1909)
Johnson, Alfred Sidney, 1860-, Radford, William A., 1865- · Chicago Radford Architectural Co · leaf 179
Fig. 70. Section of Wing Abut-ment Shown in Plate 13 (B). … Fig. 71. Plan of Wing Abut-ment Shown in Plate 13 (B). Fig. 67 is at a different angle from the other;this angle will have to be decided on for eachwing for each abutment, according to the cir-cumstances of the case—namely, the direction W^^^^^1^
Architecture · Building
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
