Worthen, William Ezra, 1819-1897, [from old catalog] ed · New York, Appleton · leaf 583
any. Figs. 1363 and 1364 is a cross-pin-tle connection of girders and struts ofthe Phoenix Iron Company with theirusual steel column. Figs. 1365 and 1S66 is a cast-ironpintle connection of the same company.Figs. 1367, 1368, and 1369 aredrawings of a cast-iron joint detail. In the present form of… … Fig. 1361, Fig. 1862,
Mechanical drawing
