Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work (1909)
Johnson, Alfred Sidney, 1860-, Radford, William A., 1865- · Chicago Radford Architectural Co · leaf 205
Fig. 7. Second-Floor Plan of Besidence. 174 PLUMBING rougliing-in measurements of every fixture heinstalls, for this will save the trouble of lookingup in the future when he may have fixtures ofthe same style to install. Let us examine thefixtures that go in on his job, and note the meas-urements… … Fig. 8. Wash Trays or Laundry Tubs. 8, with rough brass continuous waste and trapas in Fig. 9; and are to be supplied with hot andcold water through Fuller bibbs, as shown inFig. 8. The floor drain is like that shown in Fig. 10. Tlie kitchen sink is of the type illustrated inFig. 11, with…
Architecture · Building
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
