Fig. 62. Sewage Ejector—Compressed-Air T3^e—Ellis System. street sewers is an impossibility. The motivepower in this ejector may be either compressedair, steam, electricity, or water. It is applied inthe following manner: In a chamber built of 242 PLUMBING brick or iron, either in the basement… … Fig. 63. Steam and Air Type of Sewer Lift—^ElliS System. level that all the sewers and drains of the build-ing can have a good fall into it. From thereceiving tank, a discharge pipe is laid to the PLUMBING 243 point of outfall, which is generally the streetsewer. The action of the ejector is as…
