Radford's portfolio of details of building construction : a remarkable and unique collection of full-page plates, accurately drawn and reproduced to exact scale ... (1911)
Radford, William A., 1865-, Johnson, Bernard L, Rawson, Charles P · Chicago : The Radford Architectural Company · leaf 117
plan sketch, Plate 102; thespan for these beams is 20 feet. Three 2 by 12sare spiked together with the addition of a 2 by 6spiked to both sides and added to give the neces-sary width for good appearance. The lath and plaster are applied at the top of these 2 by 6s,thus exposing to view a depth of… … Dnr/jjL^ Of Ir^^iDn T&jm
Building · Architecture
