Radford's portfolio of details of building construction : a remarkable and unique collection of full-page plates, accurately drawn and reproduced to exact scale ... (1911)
Radford, William A., 1865-, Johnson, Bernard L, Rawson, Charles P · Chicago : The Radford Architectural Company · leaf 188
FRAMING FOR TILE FLOOR It is often necessary to lay a tile or mosaic floorin rooms where wood joists are used. This de-tail shows the best method of construction forthis work. The tops of all the joists under thecement foundation are beveled to prevent theconcrete from cracking. … BRICK WALL WITH AIR SPACE Cross section of hollow brick wall, S inches out-side and 1 inches inside with B 2 inch air space, bonded with metal wall ties every fifth course of brick. Since no moisture can penetrate through such a wall across this air space, tin- plaster canlie applied direct to the…
Building · Architecture
