Radford's portfolio of details of building construction : a remarkable and unique collection of full-page plates, accurately drawn and reproduced to exact scale ... (1911)
Radford, William A., 1865-, Johnson, Bernard L, Rawson, Charles P · Chicago : The Radford Architectural Company · leaf 61
ATE 48—FLOOR CONSTRUCTION AND SUPPORT Fig. 50, a 6 by 8 cellar girder resting on brickpier. Fig. 51, built-up flush girder consisting ofthree floor joists spiked together; 2 by 4 stripssupport the joist ends. Fig. 52, ordinary floorgirder with joists resting on top and spiked to- gether. Fig. 53,… … ftJJWtWtW iPObt • ■ . I* » —■—r^—■—9 - • ».^? rT^- * . .< • . * v • • . • •* • a* • * * * Md,UKS? 5<£». ^IGUKE; 55. PLATE 49—FIRE PLACE CONSTRUCTION—NON SMOKING Pig. 54, plan view showing both tile and brick struction and proper design to prevent smoking,hearth. Fig. 55, vertical section…
Building · Architecture
Internet Archive · University of Toronto, Robarts Library · Public Domain Mark 1.0. Free to use for anything.
