Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work (1909)
Johnson, Alfred Sidney, 1860-, Radford, William A., 1865- · Chicago Radford Architectural Co · leaf 73
rms, and isdischarged on the sill through perforations inthe raised lip of the sill, as at X. These perfora-tions consist of holes bored and reamed smooth.Three are usually provided for a window of ordi-nary width. The frame and sash are constructed and setso as to form a reveal on the inside of… … wm Fig. 26. Framing for Inward-Opening Casements. space, it is usually necessary to thicken the jambof the frame and provide the filling piece A. FRAJVIING 51 Shades for inwaid-opening casements areusuall} placed en the sashes, and the filling pieceshould be of a slightly greater width than…
Architecture · Building
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
