ed under ground in a 2 ft. square brickconduit. At the machine shop, the pipe branchesinto two (i in. pipes, one of which enters the shop,and the other runs parallel with the building to theproperty line, which it follows to about midway be-tween the car shop and planing mill, where it againmakes a… … VA.NIA UAII.KOA THE RAILWAY MASTER MECHANIC. expansion joints, shaped like a horse shoe. The con-duit is covered by 3 in. boards, laid crossways iu sec-tions, which can readily be removed in case of leaks. The smoke boxes are connected with a 4 ft. diame-ter brick flue, running under the ground to…
