Recent cotton mill construction and engineering (1894)
Nasmith, Joseph · London : J. Heywood · leaf 209
than whenboth cylinders are put together and the condensingapparatus put under the main slide bais, but themaker claims, with some justice, that it has theadvantages of placing the condensing apparatus ina much more accessible position, does not cut anobjectionable opening in the foundation at the•… … Fig. 71 more convenient to have the piston rod in twopieces than in one long cumbrous one, as is verycommon in the other case. 187 The main bearing used is shown in partial sectionand plan in Figs. 78 and 79. It will be noticedthe brass is divided, so that it can be set up bywedges and screws, and…
Textile factories -- Design and construction · Cotton manufacture · Cotton machinery
