International Library of Technology · Scranton, International Textbook Co. · leaf 125
to stop turning. On this account it may be 2500 DYNAMO-ELECTRIC MACHINE DESIGN. advisable to make the ring of a winding form so that it cannot lie close against the box. A small cover g is providedto span the top of the slot, to guard against the ring climb-ing up on the top of the box. The two… … Fig. 1388. left, which holds the three parts together. The oil-ringsshould not be so large in diameter as to be in danger oftouching the sides of the oil chamber ; it must be re-membered that a theoretical static clearance is not sufficient,as the ring, when turning, is carried over slightly to…
Electrical engineering
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
![An illustration from [Electric engineering.], 1902, leaf 125](https://img.insideoutlibrary.com/img/1024/ia-electricengineer02inte-125-38.webp)
