Recent cotton mill construction and engineering (1894)
Nasmith, Joseph · London : J. Heywood · leaf 47
d lines in the detailed drawings,the posts can be secured to the base plates. Theposts are bored through the centre with a Ito-hole for ventilation, and the rafters are sustainedby an iron cap fixed upon the top of the pillar. The monitor or lantern, shown in Fig. 19, issustained by a beam 16in.… … Fig. 18. \3in P/anM 3in~PlanR~, Grooyed andTTbnguec/
Textile factories -- Design and construction · Cotton manufacture · Cotton machinery
Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
