Richey's guide and assistant for carpenters and mechanics : a work of practical information, giving almost every geometrical and practical problem likely to arise in the work of the carpenter, and quick and easy methods for their solution : the use of the steel square, etc., tables showing strength and weight of materials, methods of framing, useful recipes, etc., etc. (1894)

Richey, H. G. (Harry Grant), b. 1868 · New York : W.T. Comstock · leaf 114

An illustration from Richey's guide and assistant for carpenters and mechanics : a work of practical information, giving almost every geometrical and practical problem likely to arise in the work of the carpenter, and quick and easy methods for their solution : the use of the steel square, etc., tables showing strength and weight of materials, methods of framing, useful recipes, etc., etc., 1894, leaf 114
, and with the intersection e as centreand same radius, draw the desired arc a b. 135—To Find the Pattern of Veneers for CircleSplayed Window or Door Jambs.—Draw a section ofthe frame, a| a and /;, Fig. 153; then continue the linesI d and 2 e until they meet at c; c e and c d \?> the radiusto… … Jb\ ^. F^i^- 154 equal to the slant of the sides of the hopper and draw A eat rig-ht angles to e f; with c as centre draw an arc touchingthe base line, thus finding points^and i; from these point? io8 GUIDE AND ASSISTANT draw lines parallel to the base line, touching c d at i and2; let fall…

Carpentry
