Richey's guide and assistant for carpenters and mechanics : a work of practical information, giving almost every geometrical and practical problem likely to arise in the work of the carpenter, and quick and easy methods for their solution : the use of the steel square, etc., tables showing strength and weight of materials, methods of framing, useful recipes, etc., etc. (1894)

Richey, H. G. (Harry Grant), b. 1868 · New York : W.T. Comstock · leaf 129

An illustration from Richey's guide and assistant for carpenters and mechanics : a work of practical information, giving almost every geometrical and practical problem likely to arise in the work of the carpenter, and quick and easy methods for their solution : the use of the steel square, etc., tables showing strength and weight of materials, methods of framing, useful recipes, etc., etc., 1894, leaf 129
w&U 157—To Fit Corner Washstands.floor the positionthe stand is to oc-cupy, as shown bythe dotted lines,-Fig. 183 ; then placethe stand in posi-tion, as shown, andthe distance fromthe stand along thewall to the positionit is to set is thespace to compass … FOR CARPENTERS AND MECHANICS. 123, off each side, as shown ; the distance from i to 2 is madeequal to i i. 158—To Bend a Straight Piece of MouldingOver a Circle or Segmental Head.—Take a soft pieceof the moulding and rip it into strips, as shown, keeping each member of themoulding separate ;use two…

Carpentry

Internet Archive · Boston Public Library · Public Domain Mark 1.0. Free to use for anything.
