Richey's guide and assistant for carpenters and mechanics : a work of practical information, giving almost every geometrical and practical problem likely to arise in the work of the carpenter, and quick and easy methods for their solution : the use of the steel square, etc., tables showing strength and weight of materials, methods of framing, useful recipes, etc., etc. (1894)

Richey, H. G. (Harry Grant), b. 1868 · New York : W.T. Comstock · leaf 30

An illustration from Richey's guide and assistant for carpenters and mechanics : a work of practical information, giving almost every geometrical and practical problem likely to arise in the work of the carpenter, and quick and easy methods for their solution : the use of the steel square, etc., tables showing strength and weight of materials, methods of framing, useful recipes, etc., etc., 1894, leaf 30
Tig. IT draw line from 2parallel to a d topoint 3, and continueparallel to a h. Thenlay off the thicknessof the rafter on 3 4,and draw the bevellines as shown.This rule applies toany roof. 20—To Findthe Bevel forBacking Hip Raf-ters.—Take thelength of the hip onthe blade of thesquare and the riseof… … Fig, iS 24 GUIDE AND ASSISTANT 21—To Get the Bevels to Mitre Purlins, whenthe Purlin Sets Square with the Rafters.—Draw a c e, represent-ing the slopeof the roof ;then continuec e, making- itequal in lengthto a c, 2iS d e;connect a andd, thus findingthe bevel forthe top or faceof purlins, asshown…

Carpentry

Internet Archive · Boston Public Library · Public Domain Mark 1.0. Free to use for anything.
