Fig. 17. Adjustable multiple spark-gap on Ritchie coil, as arranged by Rollins, ,Sand 7, terminalsof coil; U, ball on end of spark-gap rod C\ R, row of brass balls on strip of mica; J, wire tovacuum tube, (Rollins.) 26 THE ROENTGEN RAYS IN MEDICINE AND SURGERY … Fig. i8. Adjustable multiple spark-gap for coil.This cut shows an end view of the coil, with a simple form of adjustable multiple spark-gap,in which the brass balls are held on the side or edge of a strip of insulating material. There are twoof these on the coil, one at each end of the secondary.…
