Rogers' drawing and design; an educational treatise relating to linear drawing; machine design; working drawings; transmission methods; steam, electrical and metal working machines and parts; lathes; boiler and parts; instruments and their use; tables, etc (1913)
Hawkins, N. (Nehemiah), 1833- · New York, T. Audel · leaf 118
f the drawing. The inch is marked the foot —for example : ifoot, 3 inches is represented by i 3. More infor-mation concerning dimensions will be found in thechapter treating on working drawings. ROGERS DRAWING AND DESIGN. 133 Draw a front view, top view and right side viewof the wedge showji in… … triangle forming the front view of the wedge arethus found. Join the two ends of these sides by a straight lineand the front view is complete. The student willdraw the side view and the top view in correspond-ing positions to the right side and above the frontview, as in Fig. 239.
Mechanical drawing · Machine design
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
