icular to the center line),is an ellipse ; when the cutting plane is parallel tothe bases the section produced is a circle, just likethe bases ; when the cutting plane passes throughthe center line the section is a rectangle, two oppo-site sides of which are equal each to the height ofthe cylinder.… … Fig. 273. When the cutting plane, ab, Fig. 274, is parallelto the line cd, then the figure produced in sectionis a curve known as the parabola. Such a curve isshown in Fig. 275.
