Rogers' drawing and design; an educational treatise relating to linear drawing; machine design; working drawings; transmission methods; steam, electrical and metal working machines and parts; lathes; boiler and parts; instruments and their use; tables, etc (1913)
Hawkins, N. (Nehemiah), 1833- · New York, T. Audel · leaf 217
thinner. In the illustration the outer nutis chamfered on both faces. In Fig. 353 a bolt with a square head is shown. The distances between the parallel faces of this head is equal to i y^ times the diameter of the bolt plus y% inch. The height is equal the distance between the to ^ parallel faces.… … Fig. 356. ROGERS DRAWING AND DESIGN. 241 commonly used. The point of the set screw isusually made with an arc having a radius equal tofour times the diameter of the screw. A stud-bolt is one which is threaded at both ends.Fig. 355, one end being screwed into one of the
Mechanical drawing · Machine design
