Rogers' drawing and design; an educational treatise relating to linear drawing; machine design; working drawings; transmission methods; steam, electrical and metal working machines and parts; lathes; boiler and parts; instruments and their use; tables, etc (1913)

Hawkins, N. (Nehemiah), 1833- · New York, T. Audel · leaf 236

An illustration from Rogers' drawing and design; an educational treatise relating to linear drawing; machine design; working drawings; transmission methods; steam, electrical and metal working machines and parts; lathes; boiler and parts; instruments and their use; tables, etc, 1913, leaf 236
n a bearing, is suspended from the ceil-ing it is called a hanger. Figs. 392 to 395show the various details of a hanger made bya leading manufacturer. Fig. 392 is a sideview ; Fig. 394 the longitudinal section.This design was first introduced by Sellers,and has been reproduced and modified… … Fio. 395. Fig. 393.

Mechanical drawing · Machine design
