e adjusted, andthe spherical centers allow a considerableadjustment in other directions. This construction makes the setting up orlining up of shafting much easier and thehangers made as described above enjoytherefore the greatest popularity at thepresent time. -^■- WALL BRACKETS. When a shaft is… … ..,._51_ Figs. 393, 397 and ; ROGERS DRAWING AND DESIGN. 263 PEDESTALS AND PILLOW-BLOCKS. The words pedestal, pillow-block, bearing andjournal box are used indiscriminately. A bearing designed to support a shaft above afloor or any fixed surface is called a pedestal orpillow-block, depending upon…
