Mechanical drawing for trade schools (1911)

Leeds, Charles Carley, 1870- · New York, D. Van Nostrand company · leaf 86

An illustration from Mechanical drawing for trade schools, 1911, leaf 86 — n. The saw cut on the side of the tailstock barrel is for the purpose of allowing this part to clamp tightly around the spindle when the bind-ing screw is tightened down. The oil hole shown in the bell should be drilled after it is in placein the barrel, as it should of necessity be on the upper… … OF Material Note: For details see Dwgs. CJ030 * C.I03I ItemNo. f 1 1 Description and t^otenal \PatNo.- Req. (/) Tailstock. CI. 76 1 / 1 eg) Spindle, Corona Steel ® Screw C.R. with fHex.,\ut. Bell, C.L 77_ Hand Wheel, C. 1. 18 ® Dead Center, Tool Steel C7) Spindle Nut, Bz. (51 fixi Woodruff Key, C.…

Mechanical drawing
