Rogers' drawing and design; an educational treatise relating to linear drawing; machine design; working drawings; transmission methods; steam, electrical and metal working machines and parts; lathes; boiler and parts; instruments and their use; tables, etc (1913)
Hawkins, N. (Nehemiah), 1833- · New York, T. Audel · leaf 239
themethod described inFigs. 390 and 391 maybe employed. The bearing in thiscase is made by boringa hole through the cast-ing, and the brassesconsist of a simplesleeve, which is calleda bushing. This bushing is sim-ply turned off andbored, and is thenforced into the hole. Bearings that are made… … fitting into recesses of similar shape in the box andcap of the pillow-block. This is done to preventthem from turning with the .shaft. To prevent the brasses from sliding out endwise,they are provided with a shoulder on each end,which fits over the ends of the bearing-. Brasses of the octagonal…
Mechanical drawing · Machine design
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
