Rogers' drawing and design; an educational treatise relating to linear drawing; machine design; working drawings; transmission methods; steam, electrical and metal working machines and parts; lathes; boiler and parts; instruments and their use; tables, etc (1913)

Hawkins, N. (Nehemiah), 1833- · New York, T. Audel · leaf 320

An illustration from Rogers' drawing and design; an educational treatise relating to linear drawing; machine design; working drawings; transmission methods; steam, electrical and metal working machines and parts; lathes; boiler and parts; instruments and their use; tables, etc, 1913, leaf 320
8>% … Fig. 510. 350 ROGERS DRAWING AND DESIGN. line. The feed water enters the mud drum first,which is submerged into the hottest part of the water ;in this manner the impurities of the feed water arelargely extracted. Between the horizontal rows of tubes are placedlayers of fire brick, acting as baffle…

Mechanical drawing · Machine design

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
