Rogers' drawing and design; an educational treatise relating to linear drawing; machine design; working drawings; transmission methods; steam, electrical and metal working machines and parts; lathes; boiler and parts; instruments and their use; tables, etc (1913)
Hawkins, N. (Nehemiah), 1833- · New York, T. Audel · leaf 88
Draw two diameters, AC and BD, at right anglesto each other. Draw the lines AB, BC, CD, andDA, joining the points of intersection of these di-ameters with the circumference of the circle ACBD.ACBD is the required square. ROGERS DRAWING AND DESIGN. 101 To describe a square about a given circle. Let… … F Fig. 193. diameters intersect the circumference of the givencircle draw lines perpendicular to these diameters.These lines will intersect each other at ABCD.which is the required square. To inscribe a hexagon in a given circle. (Seedefinition, page 32.) Draw a diameter AB in the given circle,…
Mechanical drawing · Machine design
