The rudiments of architecture and building, for the use of architects, builders, draughtsmen, machinists, engineers, and mechanics (1872)

Bullock, John · Philadelphia, H.C. Baird & Co. · leaf 138

An illustration from The rudiments of architecture and building, for the use of architects, builders, draughtsmen, machinists, engineers, and mechanics, 1872, leaf 138
without diminishing the points of unity,the unity of direction being replaced by that of curvature,&c, and thus the beauty is greatly augmented. We may illustrate these principles by a figure (a) com-posed of concentric circles placed at random, and varyingIrregularly in every thing except… … ABC D centric. We gain nothing by equalizing their thicknesses 130 HISTORY AND RUDIMENTS and the spaces between them (as at b,) because this is sim-ply substituting (in both alterations) unity for variety,which, in both cases, we abandon. But in c, the two prin-ciples are reconciled, the variety in…

Architecture · Building

Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
