The rudiments of architecture and building, for the use of architects, builders, draughtsmen, machinists, engineers, and mechanics (1872)

Bullock, John · Philadelphia, H.C. Baird & Co. · leaf 194

An illustration from The rudiments of architecture and building, for the use of architects, builders, draughtsmen, machinists, engineers, and mechanics, 1872, leaf 194 — Junction of the roof and wall in anEnglish building. P. The wall-plate. T, The tie beam. R. A principal rafter. e, One of the minor rafters not ti dby the feet but thrusting out-wards, and having to be supportedby the pole-plate and a purlin (notseen) which, concentrating thewhole weight on one p…

Architecture · Building

Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
