The rudiments of architecture and building, for the use of architects, builders, draughtsmen, machinists, engineers, and mechanics (1872)

Bullock, John · Philadelphia, H.C. Baird & Co. · leaf 307

An illustration from The rudiments of architecture and building, for the use of architects, builders, draughtsmen, machinists, engineers, and mechanics, 1872, leaf 307 — pe. Mullions.—The upright shafts dividing a window into separatelight. Misereres.—Shelving seats in the stalls of churches and cathe-drals. Merlon.—The solid part of an embattled parapet. Machicolations.—The perpendicular openings left between thecorbels of a battlement over gateways and doors,…

Architecture · Building

Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
