The rudiments of architecture and building, for the use of architects, builders, draughtsmen, machinists, engineers, and mechanics (1872)

Bullock, John · Philadelphia, H.C. Baird & Co. · leaf 434

An illustration from The rudiments of architecture and building, for the use of architects, builders, draughtsmen, machinists, engineers, and mechanics, 1872, leaf 434 — lane, the long plane, thejointer, and the smoothing plane, are used for bringing thestuff to a plane surface. The jack plane is about 18 incheslong, and is used for the roughest work. The trying planeis about 22 in. long, and used after the jack plane for tryingwo, that is, taking off shavings the… … MONUMENT OF PHILOPAPPUS.—Page 276.

Architecture · Building

Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
