Science and art drawing : complete geometrical course ; consisting of plane and solid geometry, orthographic and isometric projection, projection of shadow's the principles of map projection, graphic arithmetic and graphic statics (1895)

Spanton, J. Humphrey (John Humphrey) · London : Macmillan · leaf 150

An illustration from Science and art drawing : complete geometrical course ; consisting of plane and solid geometry, orthographic and isometric projection, projection of shadow's the principles of map projection, graphic arithmetic and graphic statics, 1895, leaf 150
Fig. 254. difference of the similar figures represented by the correspondinglines ab and ca. Note.—These similar figures may be of any conceivableshape. CHAPTEE XI INSTRUMENTS FOR MEASURING ANGLES, ETC. A protractor is an instrument used for measuring or setting offangles; it may be either… … the radiating lines are drawn, and corresponds with the centreof the circle. The degrees are numbered in primary divisions, equal to tendegrees each, on the outside line from A; and on the inside linefrom B. In the actual instrument each of these primary divisionsis subdivided into ten secondary…

Geometrical drawing

Internet Archive · Wellesley College Library · Public Domain Mark 1.0. Free to use for anything.
