Science and art drawing : complete geometrical course ; consisting of plane and solid geometry, orthographic and isometric projection, projection of shadow's the principles of map projection, graphic arithmetic and graphic statics (1895)
Spanton, J. Humphrey (John Humphrey) · London : Macmillan · leaf 277
Fig. 60. 256 SOLID GEOMETRY possible solutions. Let ac and cb represent the two given sides,and A the given angle opposite one of them. It is evident thatthe resultant triangle could be either a.hc or ahc, for the two … h Ym. 61. sides and given angle are the same in both. The solution of thetriangle is amhiguous, i.e. there may be two solutions. We will give both solutions. Set out the given sides a and h in the same plane as before,which give the positions of the lines OB, OC, and OA. Atany point l on OA draw…
Geometrical drawing
