raAvn through the second division from A. POLYGONS 39 Peoblem 39. To inscribe any regular polygon in a given circle (secondmethod). For example, a nonagon. Describe a circle, and drawthe radius CA. At A draw a tan-gent to the circle. With A ascentre, and with any radius, drawa semicircle, and… … Join these points, which will Peoblem 40. On a given line AB, to describe a regular polygon.For example, a heptagon. Produce AB to C. With A as centre, and AB as radius, describe a semicircle, and divide itinto as many equal divisions asthere are sides to the polygon (inthis instance seven). Join A…
