CD, and equal to it.Draw the line EB cutting ACin F. Draw FG- parallel toAB. Draw the lines FH andGL perpendicular to AB. ThenFGLH is the square required. Problem 55. In a given triangle ABC, to inscrihean oblong having one of its sidesequal to the given line D. From A, along the base AB,set off AE… … E L B Fis. 113. Problem 56. To inscribe a square in a given circle. Draw any two diameters AB and CD at right angles toeach other. Join the extremities of these diameters.ACBD is the inscribed square required. INSCRIBED AND DESCRIBED FIGURES 47
