Kirkman, Marshall Monroe, 1842-1921 · New York, Chicago, The World Railway Publishing Company · leaf 369
MAINTENANCE OF WAY. 365 … b B Fig. 318. THE WARE TIE PLATE SURFACER AND GAUGE. E is a perspective of the combined Tie Plate Surf acer and Gauge. H is an elevation of the tool showing its use on a tie to ascertain the level of the same at points -where the tie plates are to be embedded. lis a plan showing the tool as used to…
Railroads · Transportation
Internet Archive · Smithsonian Libraries · Public domain (published before 1931). Free to use for anything.
