Select designs for public buildings; consisting of plans, elevations, perspective views, sections, and details, of churches, chapels, schools, alms-houses, gas-works, markets, and other buildings erected for public purposes (1842)

Brooks, S. H. (Samuel H.) · London : T. Kelly · leaf 304

An illustration from Select designs for public buildings; consisting of plans, elevations, perspective views, sections, and details, of churches, chapels, schools, alms-houses, gas-works, markets, and other buildings erected for public purposes, 1842, leaf 304
n the previousarch, all the joints are in lines, which, if produced, will meet in the centrea, as shown by the dotted lines. Fig. 3. Is an elliptical arch in brickwork. Fig. 4. Is an elliptical arch in stone. In arches of this form thelines of the joints, if produced, would fall on the centres of… … ■> y < -.
