Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles (1906)

Homans, James E. (James Edward), b. 1865 · New York, T. Audel & Company · leaf 263

An illustration from Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles, 1906, leaf 263 — t chamber. The simple weighted levers areshown at B, the hollow float at C, the passage for the admissionof air at /, and the passage leading to the combustion chamberat H. The operation is precisely similar to that of the other car-buretters already described. Directly above the spring nozzleis… … o

Automobiles
