Ludy, Llewellyn V., 1875- [from old catalog], American Technical Society · Chicago, American technical society · leaf 195
nd an air cushion on the other prevents it fromstriking the bottom of the dashpot. CORLISS VALVE SETTING The setting of a Corliss valve gear is a much longer processthan the setting of a plain slide valve, but is nevertheless a compara-tively simple matter, for the various adjustments are nearly… … Fig. 83. Form of Vacuum Dashpot forClosing Admission Valves VALVE GEARS 93 Wfi/STPLATBSTAND
Indicators for steam-engines · Steam-engines
