Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles (1906)

Homans, James E. (James Edward), b. 1865 · New York, T. Audel & Company · leaf 415

An illustration from Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles, 1906, leaf 415 — d down, no effect iscreated upon the brake pedal. But owing to a pin projectingin front of the small interlock on the clutch shaft, when the brakepedal is pressed down the clutch pedal is caused to go back andrelease the clutch. The brake connections run to the rear and 402 SBLF-PROPBLLED VBHICLBS.… … Fig. 309.—Mechanism of the Expanding Band Clutch of the Columbia LightCar.

Automobiles

Internet Archive · Boston College Libraries · Public Domain Mark 1.0. Free to use for anything.
