Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles (1906)
Homans, James E. (James Edward), b. 1865 · New York, T. Audel & Company · leaf 419
-e- Fig. 313.—Sectional Elevation of theDuryea Change Speed Gear. A isa spur gear screwed to the mainshaft; A, one of the three idlerpinions studded to disc, B; C, oneof the three wedges used for lock-ing B and E with friction cone, D;F, sliding sleeve on main shaft;F, ball race around F for…
Automobiles
