he circumference of the pulley or spurattached to the end of the armature shaft. This electro-dynamicforce, which tends to produce rotation of the shaft, is known asthe torque, which is to say, the twisting power of the motor. In estimating the efficient power of a motor, we have, there-fore, to… … Fig. 342.—Type of General Electric Light Vehicle Motor, with case open, showingcommutator and brush apparatus. The pinion end head is arranged for doublereduction. Both end heads and gear housing are made of aluminum. Suspensionby lugs to body. Capacity, 31J^ amperes at 39 volts; 1,800 R. v. M. at…
