Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles (1906)

Homans, James E. (James Edward), b. 1865 · New York, T. Audel & Company · leaf 503

An illustration from Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles, 1906, leaf 503 — 3*P SPEED H 1 1 l|l| 1 l|l 1 1 … Fro. 364.—Diagram of a Two-Battery-Unit, Two-Motor Circuit, showing combinations forthree speeds. The first speed is obtained with the battery units in multiple, and themotors in series; the second, with the battery units in series, and the motors inseries; the third, with the battery units in…

Automobiles

Internet Archive · Boston College Libraries · Public Domain Mark 1.0. Free to use for anything.
