Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles (1906)
Homans, James E. (James Edward), b. 1865 · New York, T. Audel & Company · leaf 559
Grossed Rods ^IrajL-rtfne of JWofion cr> … Fig. 397.—Diagram showing the positions of the eccentric throws and rods at full gearand mid-gear, when the rods are open1 and crossed11 with the crank at the for-ward dead centre, marked 1 in the previous cut. eccentric rods is meant the distance the centre of the link or thevalve would move,…
Automobiles
Internet Archive · Boston College Libraries · Public Domain Mark 1.0. Free to use for anything.
