vernier can be used asa heiglith gauge by the attachment shown in Fig. 112,This attachment can also be used in measuring the heightof recesses and shoulde^^s. Measuring Instruments 99 What is known as a micrometer depth gauge is shownin Fig. 113. With this instrument it is possible to accu-rately… … Fig. 112—A vernier caliper in use as a height gauge A surface gauge is a very important tool which is usedin marking out work to be machined. Such a gauge is il-lustrated in Fig. 114. It will be noticed that it consists
