Shop practice for home mechanics, use of tools, shop processes, construction of small machines. Contains a chapter also on theoretical mechanics and on miscellaneous information relative to shop work (1920)
Yates, Raymond F. (Raymond Francis), 1895- · New York, N. W. Henley Pub. Co. · leaf 140
A complete set of lathe tools is sho\^^l at Fig. 176.Each tool is intended for special work. The uses of thevarious lathe tools are illustrated in Fig. 177. Themechanic will readily understand these tools and their Introduction to Lathe Work 139 uses with the possible exception of the tool used in… … Facing Endof Shoiff PositiveRake - Steel N egativeRake- Brass Fig. 177—Illustrating the use of the different lathe tools shown in Fig. 176 worn they are generally brought back to shape on agrinding wheel. In grinding a tool, care should be takento see that its temper is not effected by…
Machine-shop practice · Handicraft
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
