Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 276
1061. ROTARY AND LONGITUDINALMOTION of a rod between rollers, with theiraxes at an angle. Rollers run in oppositedirections. MOTION AND DEVICES CONTROLLING MOTION. 265 1062. RECIPROCATING FEED RATCHET.— For an intermittent feed, one pair of jaws may have a /^JUj.L (^ reciprocating motion. For… … L> j^s?^^^s;?^^=?^$^^ 1063. FRICTION ROD FEED RATCHET.—The jaws, being pivoted in a slot in a lever,make a powerful and quick grip on a feedbar by the motion of the lever bar.
Mechanical movements
