Shop practice for home mechanics, use of tools, shop processes, construction of small machines. Contains a chapter also on theoretical mechanics and on miscellaneous information relative to shop work (1920)
Yates, Raymond F. (Raymond Francis), 1895- · New York, N. W. Henley Pub. Co. · leaf 169
arge car-riage bolts are used in connection with steel clamps. Theouter edges of the clamps are supported by strips ofwood which prevent them from slipping off the edge ofthe cylinder. It will also be noticed that two small stripsof Avood are interposed between the face plate and thecylinder. This… … Fig. 199—Holding bolts for use on a face plate Clamping bolts greatly increase the usefulness of theordinary face plate. Such a bolt is shown at Fig. 199 A,and at B the use of clamping bolts is made clear. Herethey are holding a small crank in place while the hub isbeing faced off. In turning a job…
Machine-shop practice · Handicraft
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
